Idler On Excavator

Idler on Excavator

The excavator guide wheel, which is also called idler, is used to guide the track to rotate correctly to prevent it from deviation and derailment. Most excavators also act as rollers. This can increase the contact area between the track and the ground and reduce the grounding specific pressure. The wheel surface of the idler supports the smooth surface. There is a retaining arm ring in the middle as a guide, and the ring surfaces on both sides support the rail chain.

The Idler Wheel

In order to make the idler wheel of excavator work and prolong its service life, the radial runout of the wheel surface to the center hole shall be less than or equal to 3mm, and it shall be correctly aligned during installation.

The Idlers

The idlers of excavator adopts the box structure cast by resin sand process, with the appearance quality of the wheel body and reasonable mechanical structure performance; The matrix is normalized to obtain good impact resistance; And rail surface medium frequency induction quenching heat treatment, the surface hardness reaches hrc48-54, and the depth of 6mm is not lower than hrc46. It has wear resistance under bad working conditions.

Excavator Idler Dimensions

Different dypes of idlers are in different dimensions. If you are looking for some brand idlers with more specific information, please feel free to contact us or leave your messages and we will get back to you witnin 12 hours.

Our Catalogue

If you can't search model which you need, please contact us.
