Excavator Information
We are mini excavator bucket manufacturers. It is good to tell that the working radius of a compact tracked excavator is a clear advantage. It does not need to be serviced and will not damage the road it works on, and it can dig in and dispose of it. It also has the ability to excavate the front of the excavator and then dispose of it on a crowded construction site. The trench operator must think twice before repositioning the excavator. The current use of bucket-wheel excavators focuses on the area of lignite and lignite mining for power generation in Germany as well as Eastern and Southeastern Europe.
Technique Data
| DIMENSIONS | |
| Overall Length | 5775mm |
| Overall Width | 2010mm |
| Overall Height | 2845mm |
| Spread of Axles | 2456mm |
| Tyre Type | 825-16 |
| Width of Grounding | 500mm |
| Track | 1595mm |
| Min Height Above Ground | 285mm |
| Width of Bulldozing | 2070mm |
| Rising Distance of Bulldozing | 470mm |
| Height of Bulldozing | 50mm |
| Width of Bucket | 700mm |
| RANGE OF OPERATION | |
| Max Digging Reach | 6520mm |
| Max Digging Depth | 3630mm |
| Max Digging Height | 6335mm |
| Max Dumping Height | 4720mm |
| Min Front Radius | 2345mm |
| Min Tail Radius | 1655mm |
| TECHNICAL SPECIFICATION | |
| Engine | YUCHAI 4F30 |
| Power/Speed | 48kw/2200rpm |
| Machine Weight | 6665kg |
| Volume of Bucket | 0.25-0.40m³ |
| Set Pressure of Main Overflow Valve | 24MPa |
| Max Digging Force | 40kN |
| Gradeability | 35° |
| Max Traction Force | 40kN |
| Max Travel Speed | 30km/h |
| Swing Speed of Platform | 10.5rpm |
| Fuel Tank Capacity | 140L |
| Hydraulic Tank Capacity | 120L |
