Basic Information
When it comes to tools and equipment for landscaping, excavators are the measure of all things. Excavators are designed to dig large holes and trenches that are compact enough for a small plot. If you need a deeper, wider hole or a smaller trench, you have an excavator. Thus, with a wide range of loads, you can find models that can transport soil, mulch and other landscaping materials that you need to move. Xinyuan excavators, however, are specially designed for this task.
Before you start digging, test the equipment before setting off. Familiarize yourself with the interior of the cab and the controls. Lift and lower the bucket and feel the movement of the front end of the machine. Find out how to reach the excavator and ask it to come to an extension so that you can reach the area that is being excavated with the most extended excavator arm. Get the equipment manual you rent for an excavator and inspect the machine with it before you start.
More Details
| DIMENSIONS | |
| Overall Length | 5775mm |
| Overall Width | 2010mm |
| Overall Height | 2845mm |
| Spread of Axles | 2456mm |
| Tyre Diameter | 855mm |
| Width of Grounding | 500mm |
| Track | 1595mm |
| Min Height Above Ground | 285mm |
| Width of Bulldozing | 2070mm |
| Rising Distance of Bulldozing | 470mm |
| Height of Bulldozing | 50mm |
| Width of Bucket | 700mm |
| RANGE OF OPERATION | |
| Max Digging Reach | 6520mm |
| Max Digging Depth | 3630mm |
| Max Digging Radius | 6335mm |
| Max Digging Height | 6525mm |
| Max Dumping Height | 4720mm |
| Min Dumping Height | 1660mm |
| Min Front Radius | 2345mm |
| Min Tail Radius | 1655mm |
| TECHNICAL SPECIFICATION | |
| Engine | YC4FA65-T300 |
| Power/Speed | 48kw/2200rpm |
| Machine Weight | 6800kg |
| Volume of Bucket | 0.30m³ |
| Set Pressure of Main Overflow Valve | 24MPa |
| Max Digging Force | 50kN |
| Gradeability | 35° |
| Pressure to the Ground | 50kpa |
| Max Traction Force | 40kN |
| Max Travel Speed | 30km/h |
| Swing Speed of Platform | 10.5rpm |
| Fuel Tank Capacity | 120L |
| Hydraulic Tank Capacity | 120L |
Excavators in Henan Flood Disaster
A terrible flood caused by heavy rain due to typhoon In-Fa happened in Henan Province last month.
The flood-stricken cities of Xinxiang and Hebi in Central China's Henan Province are engaged in an intense emergency evacuation of residents from low-lying areas due to lingering and potentially perilous waterlogging. More than 1.71 million people, or about a quarter of Xinxiang's population, are affected by the heavy rain and flooding, which has particularly hit 11 counties and districts in Xinxiang.Source
Big excavators are not only help to construct our city, but also help to save lives. We can see from the pictures, many big fellows were trying their best to help people out of this horrible flood disaster.
Stranded residents are evacuated on shovel loaders in flood-hit Xinxiang City, central China's Henan Province, July 24, 2021. (Photo: Xinhua)
(Photo: Xinjing Report)
(Photo: Xinjing Report)
Source from Global Times, web: https://www.globaltimes.cn/page/202107/1229541.shtml
