Wheel Excavator Tons

Wheel Excavator Tons Xinyuan C85 Wheel Excavator weights 8.3 tons, which belongs to small wheel excavator. It is a machine suitting for gardening, city road and other many small digging work with little demage to the road. If you need to plant many trees in an area or replant native vegetation,...

Product Details

Wheel Excavator Tons

Xinyuan C85 Wheel Excavator weights 8.3 tons, which belongs to small wheel excavator. It is a machine suitting for gardening, city road and other many small digging work with little demage to the road.

If you need to plant many trees in an area or replant native vegetation, a small wheel excavator will be the best choice for this task.

A mini excavator offers contractors and homeowners several advantages. Large excavator drivers may balk at the bouncing excavator, but there is no such thing as a small mini. A small mini feels like a big excavator. In a small space, small enough to fit through a courtyard gate.

Our excavator is able to equip a hammer and grapple as well if you need.  Here is the image of our wheel excavator with grapple for reference.

Wheel Excavator Tons

When it comes to tools and equipment for landscaping, excavators are the measure of all things. Full-grown excavators are designed to dig large holes and trenches that are compact enough for a small plot. If you need a deeper, wider hole or a smaller trench, you have an excavator. Thus, with a wide range of loads, you can find models that can transport soil, mulch, and other landscaping materials that you need to move. Cat excavators, however, are specially designed for this task.

Of course, wheel excavator for hire is very popular all around the world. You need an excavation machine with better quality and better after-sales service, which reduces the cost and increases your benefits.

Parameter

DIMENSIONS
Overall Length 6020mm
Overall Width 2250mm
Overall Height 2910mm
Spread of Axles 2500mm
Tyre Diameter 750mm
Width of Grounding 490mm
Track 1755mm
Min Height Above Ground 328mm
Width of Bulldozing 2250mm
Rising Distance of Bulldozing 500mm
Height of Bulldozing 85mm
Width of Bucket 720mm
RANGE OF OPERATION
Max Digging Reach 6800mm
Max Digging Depth 3980mm
Max Digging Height 7410mm
Max Dumping Height 5290mm
Min Front Radius 2115mm
Min Tail Radius 1945mm
TECHNICAL SPECIFICATION
Engine YUCHAI 4DK
Power/Speed 56kw/2200rpm
Machine Weight 8300kg
Volume of Bucket 0.30-0.45m³
Set Pressure of Main Overflow   Valve 25MPa
Max Digging Force 45kN
Gradeability 35°
Max Traction Force 50kN
Max Travel Speed 30km/h
Swing Speed of Platform 11rpm
Fuel Tank Capacity 180L
Hydraulic Tank Capacity 165L
